Disk I/O and SSD Stress Testing with Fio (Flexible IO Tester)

Home » #Technology » Disk I/O and SSD Stress Testing with Fio (Flexible IO Tester)

In performance-critical computing environments specially in Gaming Rig, understanding the limits of your disk subsystem is just as important as testing CPU or GPU. Whether you’re evaluating a new SSD, tuning a server for IOPS, or benchmarking storage for a high-availability system, Fio (Flexible IO Tester) is a powerful open-source tool that lets you stress test and benchmark disk I/O performance.

This tech concept, walks you through using Fio to simulate various workloads and provides hands-on examples tailored for SSDs and HDDs. For 20+ years, I’ve turned code into products and ideas into growth stories. I believe in tech’s power to transform—and I’m here to share my experience so all tech enthusiast tap into it. Your journey starts now, and it’s full of possibility.

What is Fio?

Fio (Flexible I/O Tester) is a command-line tool developed by Jens Axboe, designed to measure and stress-test storage I/O subsystems. It supports a wide range of I/O engines, offers scripting capabilities, and is highly customizable.

Why Use Fio?

Fio can simulate:

Sequential and random reads/writes
Different block sizes and I/O depths
Sync and async operations
Multiple jobs across devices or files
Latency, IOPS, and bandwidth reporting

This makes it ideal for:

Stress testing new SSDs or NVMe drives
Benchmarking RAID arrays or SAN/NAS systems
Identifying bottlenecks in disk I/O paths
Testing filesystem performance under load

Installing Fio

On Ubuntu/Debian

sudo apt update
sudo apt install fio

On CentOS/RHEL

sudo yum install fio

On macOS (via Homebrew)

brew install fio

Basic Fio Concepts

filename: Target file or block device (e.g., /dev/nvme0n1)
rw: Type of I/O pattern (read, write, randread, randwrite, etc.)
bs: Block size (e.g., 4k, 128k)
size: Total amount of data to read/write
numjobs: Number of threads/jobs
iodepth: Number of I/Os in flight
runtime: Duration of the test
direct: Use direct I/O (bypass page cache)
output-format: JSON or human-readable

Sample Fio Commands for SSD Stress Testing

1. Sequential Read Test

fio --name=seq_read --rw=read --bs=128k --size=2G --numjobs=1 --iodepth=16 --direct=1 --filename=/dev/nvme0n1 --runtime=60 --time_based

Simulates sequential read with 128KB blocks
Good for measuring throughput (MB/s)

2. Sequential Write Test

fio --name=seq_write --rw=write --bs=128k --size=2G --numjobs=1 --iodepth=16 --direct=1 --filename=/dev/nvme0n1 --runtime=60 --time_based

Tests write speed
Important for SSD endurance and logging systems

3. Random Read Test

fio --name=rand_read --rw=randread --bs=4k --size=2G --numjobs=4 --iodepth=32 --direct=1 --filename=/dev/nvme0n1 --runtime=60 --time_based

Simulates database-like small random reads
Reports IOPS and latency metrics

4. Random Write Test

fio --name=rand_write --rw=randwrite --bs=4k --size=2G --numjobs=4 --iodepth=32 --direct=1 --filename=/dev/nvme0n1 --runtime=60 --time_based

Useful for stress testing log-heavy applications

5. Mixed Read/Write Load (70/30)

fio --name=mixed_rw --rw=randrw --rwmixread=70 --bs=4k --size=2G --numjobs=4 --iodepth=16 --direct=1 --filename=/dev/nvme0n1 --runtime=60 --time_based

Emulates real-world mixed usage patterns

Output Metrics to Watch

IOPS (I/O operations per second)
Bandwidth (MB/s)
Latency (average, min, max)
CPU usage

You can also output the result in JSON and use it for dashboard visualization:

fio --name=test --rw=randread --output-format=json > fio_output.json

Best Practices for SSD Testing

Use --direct=1 to avoid caching
Ensure test file size > RAM to bypass OS cache
Avoid running on mounted filesystems for raw device tests
Use --time_based for consistent load over time
Combine with system tools like iostat, vmstat, or dstat for holistic insights

Example: Full Benchmark Script

#!/bin/bash
DEVICE="/dev/nvme0n1"

echo "Starting SSD benchmark on $DEVICE"

fio --name=seq_read --rw=read --bs=128k --size=2G --numjobs=1 --iodepth=16 --direct=1 --filename=$DEVICE --runtime=60 --time_based
fio --name=seq_write --rw=write --bs=128k --size=2G --numjobs=1 --iodepth=16 --direct=1 --filename=$DEVICE --runtime=60 --time_based
fio --name=rand_read --rw=randread --bs=4k --size=2G --numjobs=4 --iodepth=32 --direct=1 --filename=$DEVICE --runtime=60 --time_based
fio --name=rand_write --rw=randwrite --bs=4k --size=2G --numjobs=4 --iodepth=32 --direct=1 --filename=$DEVICE --runtime=60 --time_based

My Tech Advice: Disk I/O bottlenecks can cripple high-performance applications. With Fio, developers, sysadmins, and performance engineers have a powerful ally for assessing disk performance under realistic loads. Whether you’re stress testing for Gaming Rig, database servers, big data platforms, or cloud storage backends, Fio provides the detailed insights needed to build robust, high-throughput systems.
Ready to test your Gaming Rig ? Try the above tech concept, or contact me for a tech advice!
#AskDushyant

For Windows users looking to stress test and benchmark SSDs or HDDs, several reliable tools complement or substitute Fio. CrystalDiskMark is a widely-used, open-source tool that benchmarks sequential and random read/write speeds with configurable test parameters. ATTO Disk Benchmark offers detailed I/O performance insights using various transfer sizes, ideal for evaluating RAID setups or high-speed SSDs. Power users can also install Fio for Windows via WSL (Windows Subsystem for Linux) or use precompiled Windows binaries. Together, these tools offer comprehensive disk performance diagnostics tailored for Windows environments.

Note: The names and information mentioned are based on my personal experience and publicly available data; however, they do not represent any formal statement.
